And manage arc flash hazards An arc flash is a serious hazard that has the potential to cause death serious injury damage to equipment and loss of electrical supply An arc flash could be consideredas an unexpectedand violent electrical short circuit in the air that produces an arc and associated explosions of gases and molten metal 2 Complete an Arc flash study to determine safe working boundaries and PPE 1 Inform workers of the risk of the risks 2 Put up Arc flash labels on switchboard s with PPE requirements 3 Switchboards 1 Arc fault contained switchboard s 2 Arc fault Detection Design equipment to reduce incident energy

Australian electricity generators have come together and developed an Electrical Arc Flash Hazard Management Guideline to help minimise risk to electrical workers An electrical arc flash is a serious hazard that is caused by an electric current flowing through an air gap between electrical conductors which generates intense light and heat
