Polaris Belt Fitment Guide The drive belt represents one of the most critical performance links in your Polaris vehicle the link between the engine and maximum performance The Drive Belt also known as a CVT Belt Continuously Variable Transmission Belt is a key component of a snowmobile transmission system
Your Polaris QUICKDRIVETM BELT KIT is exclusively designed for your vehicle Please read the installation instructions thoroughly before beginning Installation is easier if the vehicle is clean and free of debris For your safety and to ensure a satisfactory installation perform all installation steps correctly in the sequence shown To adjust the drive belt do the following Loosen the driven clutch set screw with 7 16 wrench Using an 1 8 in Allen wrench adjust set screw until belt deflection meets specification Holding set screw with Allen wrench lightly tighten nut Using the L wrench open driven clutch sheaves 0 5 in
Polaris Belt Fitment Guide
Polaris Belt Fitment Guide
https://shop.sauer.de/media/9d/bc/cf/1638199882/Sauer_Bergegurt_gerollt.png
Rotate the driven clutch and walk the belt into the clutch Remove the clutch spreader tool from driven clutch Rotate spin the driven clutch and belt approximately 5 7 times to properly seat the belt in the driven clutch Install the clutch cover into wheel well as shown above Rotate clutch cover over A Arm 2 as shown below Use care not to
