Obs Ls Swap Wiring Guide How To Get Your LS Swapped OBS Gauges To Work I also have a video of where to move all your wires to complete the swap Bauer Performance https www faceboo

427 16K views 1 year ago ROCKWALL In my last video I covered the wiring harness modifications for a 1991 Chevy OBS truck In this video I cover in 12 minutes where I connected the main wires The back of the fuse box has a 1 4 stud A wire DIRECTLY FROM THE BATTERY needs to be run to this post A minimum of 10 GA WIRE or larger should be used This fuse box protects the entire setup so no need to fuse this connection 12v Key IGN This wire needs to see 12v with ignition on AND WHILE CRANKING Also known as IGN 1 this wire tells the
