Caterpillar Hose Products And Tooling Guide XT ES Hose Caterpillar designs and manufactures several hoses for high pressure hydraulic applications These range from 2500 to 6000 psi 17 500 to 42 000 kPa In the 6000 psi 42 000 kPa range Caterpillar offers three hoses XT 3 ES XT 5 ES and XT 6 ES ST ES exceeds SAE100R 12 13 and 15 standards

Cat hose components deliver excellent performance on all kinds of mobile and fixed plant equipment regardless of the brands in your fleet The Cat XT ES hose line up is designed and manufactured by Caterpillar for high pressure hydraulic applications These range from 2500 to 6000 psi 17 5 to 42 0 MPa The ES Enhanced Spiral construction On Cat hose the layline is color coded to indicate the hose type A few examples of the layline color code are shown in the table below A complete list can be seen in layline specification 1E1748 In addition to a layline each Cat produced hose is printed with a date code The date code is ink jet printed on the hose and contains the date

Refer to the Hose Products and Tooling Guide 6th Edition PECP5030 05 for all your hose tooling needs Also refer to the Dealer Service Tools Caterpillar Inc warrants all products sold against defects in workmanship or materials under normal use for Six Months after date of purchase unless otherwise stated except the following
