Carrier Bacnet Integration Guide You can use the Carrier controllers listed below to integrate BACnet device s with your i Vu or Field Assistant system The Carrier controller serves as a master device i Vu BACnet Link part XT LB Tru VuTM MPC Processor part TV MPCXP TruVuTM MPC Controller part TX MPCXP1628 TruVuTM MPC Controller part TX MPCXP1628 NR
RTU Open enables the unit to operate with Carrier s i Vu Open network with i Vu VAV zone controllers Fig 3 and 4 and monitored by Third Party BACnet1 Building Automation System BAS VAV RTU Open operates as part of an Open Air Terminal system using Carrier Airside Linkage or as a Standalone air source using BACnet to communicate with a The following example shows the DIP switches set for 76 8k Carrier default and BACnet MS TP 5 Connect the BACnet MS TP network to the controller s J19 Network Comm port Connect to Net Net and
