2040 Aluminum Extrusion Dimensions 20 40 Aluminium Extrusion T Slot Profile Specification Code S6 20 40 Slot Width 6 2 mm Weight 0 90 kg m Mass of Inertia lx 4 64 cm 4 ly 1 42 cm 4 Section Modulus zx 2 32 cm 3 zy 1 32 cm 3 Summary Order No HY S6 2040 T slot height 6 1 mm Section size 20 mm 40 mm Hole 5 mm Thickness of diagonal bar 1 5 mm
Aluminum Extrusion Key Design Considerations Aluminum extrusions are available in an extremely wide range of shapes and sizes and extrusion tooling is generally far lower cost than stamping dies However every manufacturing process has some limitations For aluminum extrusions there are practical limits some designs prove very challenging 2040 T slot profiles are a high quality system that is compatible with 20 series fasteners It is therefore used in professional 3D printers lasers stands and furniture It is a 20mm x 40mm metric profile that has a rectangular T slot profile with six open T slots Its smooth surface makes it resistant to dirt
